EDITORIAL

Helen Castle

5

Over the last decade, the names of Fabio Gramazio and Matthias Kohler have become

synonymous with robotics in architecture. At ETH Zurich, where they share the Chair

in Architecture and Digital Fabrication, they became in 2005 the first multipurpose

fabrication laboratory in the discipline of architecture to employ an industrial robot. As

a result, they have almost single-handedly driven robotic research in the field.

Robotics over the next few years will without a doubt become a game changer

for the entire construction industry. Greater mechanisation both on- and off-site will

enable manual labour to be minimised, as a means of achieving greater efficiencies

and cost savings. This makes it a crucial period of transition for architecture. How can

designers take early ownership of this space in order to ensure their position in the

field and concentrate technological efforts towards high-quality building design and

construction rather than just solely on operational productivity? The work of Gramazio

and Kohler at ETH Zurich and in practice keeps the focus almost wholly on the

value of robotics for the discipline of architecture. Their research highlights such key

questions as: How can robotics expand the range of production and design options for

architects by increasing the potential for greater material differentiation and complexity

of form? What are the possibilities for applying robotics at the large scale? How might,

for instance, in large-scale constructions such as the high-rise, the use of the robot cause

a shift away from standard parts to the bespoke?

As Gramazio and Kohler point out in their introduction, robotics in architecture

has the potential to recast the entire field as a practice: ‘the modern division between

intellectual work and manual production, between design and realisation, is being

rendered obsolete’ (p 14). Nowhere is it more apparent in this issue that both the

approach and profession of architects are being reshaped than in the exciting section on

entrepreneurship in architectural robotics (pp 60–75). Startups are proving an entirely

new and innovative nexus between academic research and the construction industry. On

a tech model, agile outfits are stepping in and attempting to benefit from current gaps

in knowledge and technologies. Introduced by Jelle Feringa, Chief Technology Officer

at Odico Formwork Robotics, a 15-strong company that specialises in formwork

production and research and development (R&D) technology, this extended article

features five startups located in Funen in Denmark, London, Los Angeles, Princeton in

New Jersey and Zurich.

The extent to which robotics in architecture has the potential to bring about real

change globally and influence the quality of the wider built environment is brought

to the fore in Tom Verebes’ Counterpoint to the issue (pp 126 –33). Nowhere are the

stakes higher than in China and Southeast Asia where rapid urbanisation has meant

that there is a relentless and almost unmeetable demand for high-rise housing in

burgeoning cities. From his base in Hong Kong, Verebes questions the real possibilities

for mass adoption of robotics in construction in Chinese cities in a way that could

lead to the development of differentiated and bespoke architectures. What is apparent,

though, is that it is only with the type of pioneering research that Gramazio and

Kohler and their colleagues are undertaking at ETH Zurich and the associated Future

Cities Laboratory (FCL) in Singapore that architects will ever have the hope of being

significant players at the table when the international construction industry comes to

the point of rolling out on-site automated building techniques. 1

Text © 2014 John Wiley & Sons Ltd. Image

© Illustration by Frances Castle

5

6

Gramazio & Kohler in cooperation with

Bearth & Deplazes, Gantenbein vineyard

facade, Fläsch, Switzerland, 2006

top: The masonry bond with the gaps between

the bricks creates subdued interior lighting. The

sunlight shining through produces fascinating

illumination effects.

Gramazio & Kohler and Raffaello D’Andrea in cooperation

with ETH Zurich, Flight Assembled Architecture, FRAC

Centre, Orléans, France, 2012

bottom left: The final installation of Flight Assembled Architecture

consists of over 1,500 modules which are placed by a multitude

of quad-rotor helicopters, collaborating according to mathematical

algorithms that translate digital design data to the behaviour of the

flying machines.

Fabio Gramazio and Matthias Kohler,

Structural Oscillations, Architecture and Digital

Fabrication, ETH Zurich, Venice Architecture

Biennale, 2008

bottom right: Interior view of the Swiss Pavilion with

its 100-metre (328-foot) long robotic fabricated wall.

6

7

Fabio Gramazio and Matthias Kohler are architects with

multidisciplinary interests ranging from computational design and

robotic control and fabrication, to material innovation. In 2000 they

founded the architecture practice Gramazio & Kohler, which has realised

numerous award-winning projects integrating novel architectural designs

within a contemporary building culture. Current projects include the

design of the NEST research platform, a future living and working

laboratory for sustainable building construction. Built work ranges from

international exhibitions and private and public buildings, to large-scale

urban interventions, including the Gantenbein vineyard facade (Fläsch,

Switzerland, 2006), the Tanzhaus theatre for contemporary dance

(Zurich, 2007), the Christmas lights for Bahnhofstrasse, Zurich (2003–

5), and the sWISH* pavilion at the Swiss National Exposition Expo.02

(Biel, Berne, 2002).

Opening also the world’s first architectural robotic laboratory at

ETH Zurich, Gramazio & Kohler’s research has been formative in the

field of digital architecture, setting precedence and de facto creating a

new research field merging advanced architectural design and additive

fabrication processes through the customised use of industrial robots.

This ranges from 1:1 prototype installations to robotic fabrication at

a large scale, which is explored at the Future Cities Laboratory of the

Singapore ETH-Centre for Environmental Sustainability (SEC) and

exclusively featured in this issue of 3.

Gramazio & Kohler were awarded the Swiss Art Award in 2004, the

Acadia Award for Emerging Digital Practice in 2009, and the Global

Holcim Innovation Prize in 2012. Their innovative explorations have

contributed to numerous exhibitions around the world, with installations

such as Structural Oscillations at the 2008 Venice Architecture Biennale,

Pike Loop at the Storefront for Art and Architecture in New York in

2009, and Flight Assembled Architecture at the FRAC Centre, Orléans,

France, in 2011–12. Their work has been published in many journals,

books and media, and was first documented in their book Digital

Materiality in Architecture (Lars Müller Publishers, 2008). Their recent

research is outlined and theoretically framed in the book The Robotic

Touch: How Robots Change Architecture (Park Books, 2014). Together with

leading researchers in architecture, material sciences, computation and

robotics, they have just launched the first architectural National Centre

of Competence in Research on Digital Fabrication. 1

ABOUT THE GUEST-EDITORS

FABIO GRAMAZIO AND MATTHIAS KOHLER

Text © 2014 John Wiley & Sons Ltd. Images:

p 6(t) © Ralph Feiner; p 6bl) © FRAC Centre,

photography François Lauginie; p 6(br) ©

Alessandra Bello; p 7 © Juventino Mateo

7

SPOTLIGHT

8

Flight Assembled Architecture, FRAC

Centre, Orléans, France, 2011

Leaving the common workspace of conventional

digitally controlled production machines, flying

robots can operate freely in airspace. Here they

assemble collaboratively over 1,500 building

modules into a vertical urban structure.

Gramazio & Kohler and

Raffaello D’Andrea in

cooperation with ETH

Zurich

9

10

Sartorial Techtonics folded panel system, 2013

RoboFold developed a folded panel system based on textile

folding patterns for Andrew Saunders of Rensselaer Polytechnic

Institute (RPI) in New York. The project takes its inspiration from

traditional pleating techniques, and specifically the box pleat.

Folds in the cloth are translated directly to metal through material

simulation and physical experimentation. A total of 11 panels

were produced as a part of 1:1 facade mock-up, and shipped to

the US to be assembled and exhibited at RPI.

RoboFold

11

Programmed Article Transfer, by

George Charles Devol, Jr., issued

13 June 1961

Devol applied for the patent on 10

December 1954, the document

extending over a mere three pages.

Original patent of the first

industrial robot

12
